HDM12 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CIRCULAR DIN CONNECTORS HEAVY DUTY M12 CIRCULAR METRIC CONNECTOR, A CODE, HIGH TEMPERATURE, METAL, 4A, 05 PINS, MALE CONNECTOR, MALE CONTACT, HEXAGONAL, M16*1.5, SCREW THREAD, RECEPTACLE, PCB 180 , RECEPTACLE, FRONT FASTEN, IP68 / IP69K
| Part | Contact Material | Operating Temperature (Max) | Operating Temperature (Min) | Shielding | Shell Material | Fastening Type | Voltage Rating | Orientation | Insert Material | Mounting Type | Current Rating | Mounting Feature | Ingress Protection Description | Ingress Protection IP Rating | Contact Finish - Mating | Number of Positions | Connector Type | Termination | Primary Material | Shell Size - Insert | Color | Features | Cable Opening (Max) | Cable Opening (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Copper Alloy | 125 °C | -40 °C | Unshielded | Thermoplastic | Threaded | 60 V | A | Thermoplastic | Panel Mount Through Hole | 4 A | Bulkhead Front Side Nut | Dust Tight Water Resistant Waterproof | IP68 IP69K | Gold | 5 | Male Pins Receptacle | Solder | Plastic | M12-5 | Black | |||
 McGill Microwave Systems | Copper Alloy | 125 °C | -40 °C | Unshielded | Thermoplastic | Threaded | 60 V | A | Thermoplastic | Free Hanging (In-Line) | 4 A | Dust Tight Waterproof | IP67 | Gold | 5 | Female Sockets Plug | Solder Cup | Plastic | M12-5 | Black | Backshell Coupling Nut | 0.295 in | 0.157 in |
