073406 Series

Manufacturer: Molex

Catalog

SMP JACK TO JACK ADAPTER 50 OHM

Part	Center Contact Material	Body Material	Dielectric Material	Body Finish	Center Contact Plating	Convert From (Adapter End)	Mounting Type	Center Gender	Frequency - Max	Adapter Type	Conversion Type	Fastening Type	Impedance	Convert To (Adapter End)	Style	Adapter Series	Housing Color	Connector Style	Contact Termination	Number of Ports	Connector Type	Shield Termination	Features	Voltage Rating	Operating Temperature (Min)	Operating Temperature (Max)
Molex 0734066400	Beryllium Copper	Beryllium Copper	Polytetrafluoroethylene (PTFE)	Gold	Gold	Female Socket SMP Jack	Free Hanging (In-Line)	Female	40 Gbps	Jack to Jack	Same Series	Snap-On	50 Ohm	Female Socket SMP Jack	Straight	SMP to SMP
Molex 0734060530	Beryllium Copper	Beryllium Copper	Polytetrafluoroethylene (PTFE)	Gold	Gold	Female Socket SMP Jack	Free Hanging (In-Line)	Female	40 Gbps	Jack to Jack	Same Series	Snap-On	50 Ohm	Female Socket SMP Jack	Straight	SMP to SMP
Molex 0734060480	Brass						Surface Mount		40 Gbps			Snap-On	50 Ohm				Gold	SMP	Solder	1	Male Pin Plug	Solder
Molex 0734066840	Brass	Brass	Polyetheretherketone (PEEK)	Gold	Gold		Through Hole		40 Gbps			Snap-On	50 Ohm				Gold	SMP	Solder	1	Male Pin Plug	Solder	Smooth Bore
Molex 0734066061	Brass	Brass	Liquid Crystal Polymer (LCP)	Gold	Gold		Right Angle Surface Mount		26.5 GHz			Snap-On	50 Ohm				Gold	SMP	Solder	1	Male Pin Plug	Solder	Limited Detent	335 V
Molex 0734066180	Brass	Brass	Polytetrafluoroethylene (PTFE)	Gold	Gold		Board Edge Cutout Surface Mount					Snap-On	50 Ohm				Gold	SMP	Solder	1	Male Pin Plug	Solder	Limited Detent
Molex 0734066360	Beryllium Copper	Beryllium Copper	Polytetrafluoroethylene (PTFE)	Gold	Gold		Through Hole		40 Gbps			Snap-On	50 Ohm				Gold	SMP	Solder	1	Female Socket Jack	Solder		335 V	-65 °C	165 °C
