2321926 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HEADERS & WIRE HOUSINGS RECEPTACLE HOUSING PANEL MOUNT 2PIN
| Part | Number of Positions | Contact Type | Number of Rows | Contact Termination | Fastening Type | Mounting Type | Features | Color | Insulation Material | Connector Type | Operating Temperature (Min) | Operating Temperature (Max) | Pitch | Note |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 2 | Tab | 1 | Crimp | Locking Ramp | Panel Mount Snap-In | Glow Wire Compliant Sealed | Natural | Nylon 6/6 Polyamide (PA66) | Receptacle | -30 °C | 105 °C | 0.098 in | Contacts Not Included |
 TE Connectivity AMP Connectors | 6 | Tab | 1 | Crimp | Locking Ramp | Panel Mount Snap-In | Glow Wire Compliant Sealed | Natural | Nylon 6/6 Polyamide (PA66) | Receptacle | -30 °C | 105 °C | 0.098 in | Contacts Not Included |
 TE Connectivity AMP Connectors | 3 | Tab | 1 | Crimp | Locking Ramp | Panel Mount Snap-In | Glow Wire Compliant Sealed | Natural | Nylon 6/6 Polyamide (PA66) | Receptacle | -30 °C | 105 °C | 0.098 in | Contacts Not Included |
 TE Connectivity AMP Connectors | 5 | Tab | 1 | Crimp | Locking Ramp | Panel Mount Snap-In | Glow Wire Compliant Sealed | Natural | Nylon 6/6 Polyamide (PA66) | Receptacle | -30 °C | 105 °C | 0.098 in | Contacts Not Included |
 TE Connectivity AMP Connectors | 4 | Tab | 1 | Crimp | Locking Ramp | Panel Mount Snap-In | Glow Wire Compliant Sealed | Natural | Nylon 6/6 Polyamide (PA66) | Receptacle | -30 °C | 105 °C | 0.098 in | Contacts Not Included |
