ISL6567 Series

Catalog

MULTIPURPOSE TWO-PHASE BUCK PWM CONTROLLER WITH INTEGRATED MOSFET DRIVERS

Part	Package / Case	Package Width	Package Name	Package Length	Operating Temperature (Max)	Operating Temperature (Min)	Function	Control Features	Duty Cycle (Max)	Output Configuration	Frequency - Switching (Max)	Frequency - Switching (Min)	Number of Outputs	Mounting Type	Clock Sync	Topology	Synchronous Rectifier	Output Phases	Voltage - Supply (Vcc/Vdd) Minimum	Voltage - Supply (Vcc/Vdd) Maximum	Output Type
Renesas Electronics Corporation ISL6567IRZ-T	24-VFQFN Exposed Pad	4 mm	24-QFN	4 mm	85 °C	-40 °C	Step-Down	Enable Frequency Control Soft Start	66 %	Positive	2 MHz	200 kHz	2	Surface Mount	No	Buck	Yes	2	4.9 V	5.5 V	Transistor Driver
Renesas Electronics Corporation ISL6567CRZ	24-VFQFN Exposed Pad	4 mm	24-QFN	4 mm	70 °C	0 °C	Step-Down	Enable Frequency Control Soft Start	66 %	Positive	2 MHz	200 kHz	2	Surface Mount	No	Buck	Yes	2	4.9 V	5.5 V	Transistor Driver
Renesas Electronics Corporation ISL6567CRZ-T	24-VFQFN Exposed Pad	4 mm	24-QFN	4 mm	70 °C	0 °C	Step-Down	Enable Frequency Control Soft Start	66 %	Positive	2 MHz	200 kHz	2	Surface Mount	No	Buck	Yes	2	4.9 V	5.5 V	Transistor Driver
Renesas Electronics Corporation ISL6567IRZ	24-VFQFN Exposed Pad	4 mm	24-QFN	4 mm	85 °C	-40 °C	Step-Down	Enable Frequency Control Soft Start	66 %	Positive	2 MHz	200 kHz	2	Surface Mount	No	Buck	Yes	2	4.9 V	5.5 V	Transistor Driver
