S Series

Catalog

CERAMIC DISC CAPACITORS S 3KV 100PF +/-5% SL0 BULK E3

Part	Capacitance	Voltage - Rated	Operating Temperature (Max)	Operating Temperature (Min)	Tolerance	Mounting Type	Temperature Coefficient	Package / Case	Applications	Size / Dimension Diameter	Lead Style	Lead Spacing	Height - Seated (Max)
Vishay Dale S101J43SL0R63L7R	100 pF	3000 V	125 °C	-55 °C	5 %	Through Hole	SL	Disc Radial	General Purpose
Vishay Dale S820J29SL0N6UJ5R	82 pF	1000 V	125 °C	-55 °C	5 %	Through Hole	SL	Disc Radial	General Purpose	0.295 in	Straight	0.197 in	0.453 in
Vishay Dale S470K25SL0N6TJ5R	47 pF	1000 V	125 °C	-55 °C	10 %	Through Hole	SL	Disc Radial	General Purpose	0.256 in	Straight	0.197 in	0.413 in
Vishay Dale S680J29SL0N63J5R	68 pF	1000 V	125 °C	-55 °C	5 %	Through Hole	SL	Disc Radial	General Purpose	0.295 in	Straight	0.197 in	0.453 in
Vishay Dale S332K47X7RN63J7R	3300 pF	1000 V	125 °C	-55 °C	10 %	Through Hole	X7R	Disc Radial	General Purpose
Vishay Dale S152K39Y5PP6UK5R	1500 pF	2000 VAC	125 °C	-30 °C	10 %	Through Hole	Y5P (B)	Disc Radial	General Purpose	0.394 in	Formed Leads - Kinked	0.197 in	0.551 in
Vishay Dale S222K39Y5PN6UJ5R	2200 pF	1000 V	125 °C	-30 °C	10 %	Through Hole	Y5P (B)	Disc Radial	General Purpose
Vishay Dale S101J39SL0P63K5R	100 pF	2000 VAC	125 °C	-55 °C	5 %	Through Hole	SL	Disc Radial	General Purpose	0.394 in	Formed Leads - Kinked	0.197 in	0.551 in
Vishay Dale S121K39SL0P63K5R	120 pF	2000 VAC	125 °C	-55 °C	10 %	Through Hole	SL	Disc Radial	General Purpose	0.394 in	Formed Leads - Kinked	0.197 in	0.551 in
Vishay Dale S103M47Z5UN63K7R	10000 pF	1000 V	125 °C	-30 °C	20 %	Through Hole	Z5U	Disc Radial	General Purpose	0.472 in	Straight	0.295 in	0.661 in
