XC2C384 Series

Catalog

IC CPLD 384MC 9.2NS 208QFP

Part	Delay Time tpd(1) Max	Voltage Supply - Internal (Minimum)	Voltage Supply - Internal (Maximum)	Number of Macrocells	Number of Gates	Package / Case	Number of I/O	Number of Logic Elements/Blocks	Mounting Type	Package Width	Package Name	Package Length	Operating Temperature (Min)	Operating Temperature (Max)	Programmable Type
AMD / Xilinx XC2C384-10PQG208C	9.2 ns	1.7 V	1.9 V	384	9000	208-BFQFP	173	24	Surface Mount	28 mm	208-PQFP	28 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-10PQ208C	9.2 ns	1.7 V	1.9 V	384	9000	208-BFQFP	173	24	Surface Mount	28 mm	208-PQFP	28 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-10FTG256C	9.2 ns	1.7 V	1.9 V	384	9000	256-LBGA	212	24	Surface Mount	17 mm	256-FTBGA	17 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-10FGG324C	9.2 ns	1.7 V	1.9 V	384	9000	324-BBGA	240	24	Surface Mount	23 mm	324-FBGA	23 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-7PQ208C	7.1 ns	1.7 V	1.9 V	384	9000	208-BFQFP	173	24	Surface Mount	28 mm	208-PQFP	28 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-7TQ144C	7.1 ns	1.7 V	1.9 V	384	9000	100-LQFP 144-LQFP	118	24	Surface Mount	14 mm 20 mm	100-TQFP 144-TQFP	14 mm 20 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-10TQ144I	9.2 ns	1.7 V	1.9 V	384	9000	100-LQFP 144-LQFP	118	24	Surface Mount	14 mm 20 mm	100-TQFP 144-TQFP	14 mm 20 mm	-40 °C	85 °C	In System Programmable
AMD / Xilinx XC2C384-10TQ144C	9.2 ns	1.7 V	1.9 V	384	9000	100-LQFP 144-LQFP	118	24	Surface Mount	14 mm 20 mm	100-TQFP 144-TQFP	14 mm 20 mm	0 °C	70 °C	In System Programmable
AMD / Xilinx XC2C384-10FT256I	9.2 ns	1.7 V	1.9 V	384	9000	256-LBGA	212	24	Surface Mount	17 mm	256-FTBGA	17 mm	-40 °C	85 °C	In System Programmable
