NBN8-18 Series
Manufacturer: Pepperl+Fuchs, Inc.
Beta
⌘K
INDUCTIVE PROXIMITY SENSOR, BASIC SERIES, 8 MM, CYLINDRICAL, SPST-NO, 20 VAC TO 253 VAC, CONNECTOR
| Part | Material - Body | Sensor Type | Ingress Protection | Shielding | Termination Style | Package / Case | Sensing Distance | Indicator | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Output Type | Operating Temperature (Max) | Operating Temperature (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | IP67 | Unshielded | Cable | Cylinder Threaded - M18 | 0.315 " | LED | 253 V | 20 VDC | 2-Wire SCR-NO | 70 °C | -25 °C |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | IP67 | Unshielded | Connector | Cylinder Threaded - M18 | 0.315 " | LED | 253 V | 20 VDC | 2-Wire SCR-NO | 70 °C | -25 °C |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | IP67 | Unshielded | Connector | Cylinder Threaded - M18 | 0.315 " | LED | 30 VDC | 10 VDC | 3-Wire PNP-NO | 70 °C | -40 °C |
 Pepperl+Fuchs, Inc. | Nickel-Plated Brass | Inductive | IP67 | Unshielded | Cable | Cylinder Threaded - M18 | 0.315 " | LED | 30 VDC | 10 VDC | 3-Wire PNP-NO | 70 °C | -25 °C |
