ADL8109 Series

High Survivability, Low Noise Amplifier, 1 GHz to 20 GHz

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

High Survivability, Low Noise Amplifier, 1 GHz to 20 GHz

Part	Frequency (Min)	Frequency (Max)	Noise Figure	Current - Supply	P1dB	RF Type	Package / Case	Mounting Type	Package Length	Package Name	Package Width	Gain	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Test Frequency (Minimum)	Test Frequency (Maximum)
Analog Devices Inc./Maxim Integrated ADL8109ACPZN-R7	1 GHz	20 GHz	4.5 dB	100 mA	16.5 dBm	Radar	8-VFDFN Exposed Pad CSP	Surface Mount	2 mm	8-LFCSP	2 mm	15 dB	6 V	3 V	1 GHz	8 GHz
Analog Devices Inc./Maxim Integrated ADL8109ACPZN	1 GHz	20 GHz	4.5 dB	100 mA	16.5 dBm	Radar	8-VFDFN Exposed Pad CSP	Surface Mount	2 mm	8-LFCSP	2 mm	15 dB	6 V	3 V	1 GHz	8 GHz

Catalog

High Survivability, Low Noise Amplifier, 1 GHz to 20 GHz

Description

The ADL8109 is a 1 GHz to 20 GHz low noise amplifier (LNA) with 36.5 dBm RF input power survivability. The ADL8109 has a gain of 15 dB, an ouptut power for 1 dB compression (OP1dB) of 16 dBm, a typical output third-order intercept (OIP3) of 28 dBm, and a noise figure of 3 dB from 8 GHz to 18 GHz. This LNA operates on a 5 V supply voltage (VDD) and has a nominal quiescent current (IDQ) of 110 mA. The ADL8109 also features an RF input and output that are internally matched to 50 Ω.The device is housed in a RoHS-compliant, 2 mm × 2 mm, 8-lead lead frame chip scale package [LFCSP] and is specified for operation from −55°C to +125°C.APPLICATIONSTelecommunicationsSatellite communicationsMilitary radarCivil radarElectronic warfareTest and measurement equipment
