AD9699 Series

Catalog

1-CHANNEL SINGLE ADC PIPELINED 3GSPS 14-BIT JESD204B 196-PIN TEBGA TRAY

Part	Mounting Type	Ratio - ADC	Ratio - S/H	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 3 Min)	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 3 Max)	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Data Interface	Package Name	Package Width	Package Length	Operating Temperature (Min)	Operating Temperature (Max)	Number of Bits	Architecture	Number of Inputs	Sampling Rate (Per Second)	Input Type	Reference Type	Package / Case	Number of A/D Converters	Configuration	Voltage - Supply, Digital (Range 2) Maximum	Voltage - Supply, Digital (Range 1) Maximum	Voltage - Supply, Digital (Range 2) Minimum	Voltage - Supply, Digital (Range 1) Minimum	Grade	Qualification
Analog Devices Inc./Maxim Integrated AD9699BBPZ-3000	Surface Mount	1	1	1 V	1.95 V	1.85 V	2.44 V	0.95 V	2.56 V	1 V	0.95 V	JESD204B	196-BGA-ED	12 mm	12 mm	-40 °C	85 °C	14 bits	Pipelined	1	3 GHz	Single Ended	External	196-LFBGA Exposed Pad	1 count	S/H-ADC
Analog Devices Inc./Maxim Integrated AD9699WBBPZRL-3000	Surface Mount	1	1	1 V	1.95 V	1.85 V	2.44 V	0.95 V	2.56 V			JESD204B	196-BGA-ED	12 mm	12 mm	-40 °C	105 °C	14 bits	Pipelined	1	3 GHz	Single Ended	External	196-LFBGA Exposed Pad	1 count	S/H-ADC	1.95 V	1 V	1.85 V	0.95 V	Automotive	AEC-Q100
Analog Devices Inc./Maxim Integrated AD9699BBPZRL-3000	Surface Mount	1	1	1 V	1.95 V	1.85 V	2.44 V	0.95 V	2.56 V	1 V	0.95 V	JESD204B	196-BGA-ED	12 mm	12 mm	-40 °C	105 °C	14 bits	Pipelined	1	3 GHz	Single Ended	External	196-LFBGA Exposed Pad	1 count	S/H-ADC
