ADF4252 Series

Catalog

CLOCK GENERATOR 50MHZ TO 3GHZ-IN 24-PIN LFCSP EP T/R

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Width	Package Name	Package Length	Mounting Type	Input	Type	PLL	Output Ratio	Input Ratio	Package / Case	Multiplier	Divider	Output	Frequency - Max	Differential Input	Differential Output	Number of Circuits	Operating Temperature (Min)	Operating Temperature (Max)
Analog Devices Inc./Maxim Integrated ADF4252BCPZ-RL	3.3 V	2.7 V	4 mm	24-LFCSP-WQ	4 mm	Surface Mount	CMOS TTL	Clock/Frequency Synthesizer (RF/IF) Fractional N Integer N	Yes	2	3	24-WFQFN Exposed Pad CSP	No	Yes	Clock	3 GHz	Yes	No	1	-40 °C	85 °C
Analog Devices Inc./Maxim Integrated ADF4252BCPZ	3.3 V	2.7 V	4 mm	24-LFCSP-WQ	4 mm	Surface Mount	CMOS TTL	Clock/Frequency Synthesizer (RF/IF) Fractional N Integer N	Yes	2	3	24-WFQFN Exposed Pad CSP	No	Yes	Clock	3 GHz	Yes	No	1	-40 °C	85 °C
Analog Devices Inc./Maxim Integrated ADF4252BCP	3.3 V	2.7 V	4 mm	24-LFCSP-WQ	4 mm	Surface Mount	CMOS	Clock/Frequency Synthesizer (RF/IF) Fractional N Integer N	Yes	2	3	24-WFQFN Exposed Pad CSP	No	Yes	Clock	3 GHz	Yes	No
Analog Devices Inc./Maxim Integrated ADF4252BCPZ-R7	3.3 V	2.7 V	4 mm	24-LFCSP-WQ	4 mm	Surface Mount	CMOS TTL	Clock/Frequency Synthesizer (RF/IF) Fractional N Integer N	Yes	2	3	24-WFQFN Exposed Pad CSP	No	Yes	Clock	3 GHz	Yes	No	1	-40 °C	85 °C
Analog Devices Inc./Maxim Integrated ADF4252BCP-REEL7	3.3 V	2.7 V	4 mm	24-LFCSP-WQ	4 mm	Surface Mount	CMOS	Clock/Frequency Synthesizer (RF/IF) Fractional N Integer N	Yes	2	3	24-WFQFN Exposed Pad CSP	No	Yes	Clock	3 GHz	Yes	No
