8A-03PFFS Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
M SERIES SENSOR CONNECTOR, GUIDED M8, METAL, 3A, 03 PINS, FEMALE CONNECTOR, FEMALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER, REC
| Part | Termination | Contact Material | Insert Material | Color | Ingress Protection Description | Ingress Protection IP Rating | Connector Type | Number of Positions | Shell Size - Insert | Material Flammability Rating | Primary Material | Current Rating | Mounting Type | Shielding | Voltage Rating | Shell Finish | Contact Finish - Mating | Operating Temperature (Min) | Operating Temperature (Max) | Shell Material | Orientation | Fastening Type | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Solder Cup | Copper Alloy | Glass Filled Nylon PA Polyamide | Silver | Dust Tight Waterproof | IP67 | Female Sockets Plug | 3 | M8-3 | UL94 V-0 | Metal | 3 A | Panel Mount | Shielded | 60 V | Nickel | Gold | -40 °C | 105 °C | Zinc Alloy | Keyed | Threaded | Bulkhead Rear Side Nut |
