164A107 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN D-SUB RCPT 50POS R/A SLDR
| Part | Connector Type | Number of Rows | Ingress Protection | Mounting Type | Material Flammability Rating | Backset Spacing | Termination | Connector Style | Contact Type | Contact Finish | Finish | Shell Material | Current Rating | Flange Feature | Number of Positions | Features | Shell Size | Connector Layout | Dielectric Material | Contact Material | Color | Operating Temperature (Max) | Operating Temperature (Min) | Contact Form | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Female Sockets Receptacle | 3 | IP20 | Right Angle Through Hole | UL94 V-0 | 0.37 in | Solder | D-Sub | Signal | Gold | Tin Plated | Steel | 7.5 A | Housing Shell (Unthreaded) | 50 | Mounting Brackets | 5 | D DD | Glass Filled Polybutylene Terephthalate (PBT) | Copper Alloy | Black | 125 °C | -55 °C | Machined | 125 V |
McGill Microwave Systems | Female Sockets Receptacle | 2 | Right Angle Through Hole | 0.37 in | Solder | D-Sub | Signal | Tin Plated | Steel | Housing Shell (4-40) | 15 | Mounting Brackets | 2 | A DA | |||||||||||
 McGill Microwave Systems | Female Sockets Receptacle | 2 | Right Angle Through Hole | 0.37 in | Solder | D-Sub | Signal | Tin Plated | Steel | Housing Shell (4-40) | 9 | Mounting Brackets | 1 | DE E | |||||||||||
McGill Microwave Systems | Female Sockets Receptacle | 2 | Right Angle Through Hole | 0.37 in | Solder | D-Sub | Signal | Tin Plated | Steel | Housing Shell (4-40) | 37 pos | Mounting Brackets | 4 | C DC | |||||||||||
 McGill Microwave Systems | Female Sockets Receptacle | 3 | Right Angle Through Hole | 0.37 in | Solder | D-Sub | Signal | Gold | Tin Plated | Steel | Housing Shell (4-40) | 50 | Mounting Brackets | 5 | D DD | 125 °C | -55 °C |
