97-3101A22 Series

Manufacturer: Amphenol Aerospace Operations

Catalog

CONN RCPT MALE 19P SOLDER CUP

Part	Fastening Type	Number of Positions	Shell Finish	Termination	Connector Type	Insert Material	Shell Material	Applications	Contact Material	Mounting Type	Shielding	Features	Operating Temperature (Max)	Operating Temperature (Min)	Contact Finish - Mating	Primary Material	Color	Shell Size - Insert Width	Shell Size - Insert Length	Orientation	Backshell Material	Plating	Shell Size - Insert (Maximum)	Shell Size - Insert (Minimum)
Amphenol Aerospace Operations 97-3101A-22-14P	Threaded	19	Cadmium Olive Drab Chromate	Solder Cup	Male Pins Receptacle	DAP Diallyl Phthalate	Aluminum Alloy	Automotive Industrial	Copper Alloy	Free Hanging (In-Line)	Unshielded	Backshell	125 °C	-55 °C	Silver	Metal	Olive Drab	14 mm	22 mm	N (Normal)	Aluminum Alloy	Olive Drab Chromate over Cadmium
Amphenol Aerospace Operations 97-3101A-22-22S	Threaded	4	Cadmium Olive Drab Chromate	Solder Cup	Female Sockets Receptacle	DAP Diallyl Phthalate	Aluminum Alloy	Automotive Industrial	Copper Alloy	Free Hanging (In-Line)	Unshielded	Backshell	125 °C	-55 °C	Silver	Metal	Olive Drab			N (Normal)	Aluminum Alloy	Olive Drab Chromate over Cadmium	22	22
Amphenol Aerospace Operations 97-3101A-22-18S	Threaded	8	Cadmium Olive Drab Chromate	Solder Cup	Female Sockets Receptacle	DAP Diallyl Phthalate	Aluminum Alloy	Automotive Industrial	Copper Alloy	Free Hanging (In-Line)	Unshielded	Backshell	125 °C	-55 °C	Silver	Metal	Olive Drab	18 mm	22 mm	N (Normal)	Aluminum Alloy	Olive Drab Chromate over Cadmium
Amphenol Aerospace Operations 97-3101A-22-2S	Threaded	3	Cadmium Olive Drab Chromate	Solder Cup	Female Sockets Receptacle	DAP Diallyl Phthalate	Aluminum Alloy	Automotive Industrial	Copper Alloy	Free Hanging (In-Line)	Unshielded	Backshell	125 °C	-55 °C	Silver	Metal	Olive Drab	2 mm	22 mm	N (Normal)	Aluminum Alloy	Olive Drab Chromate over Cadmium
