SOMC Series

Catalog

RESISTOR NETWORKS & ARRAYS 16PIN 330OHMS 2% ISOLATED

Part	Size / Dimension Width	Size / Dimension Length	Circuit Type	Temperature Coefficient	Resistance	Package Width	Package Name	Package Length	Mounting Type	Number of Pins	Power Per Element	Height - Seated (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Number of Resistors	Tolerance
Vishay Dale SOMC1603330RGEA	0.22 in	0.44 in	Isolated	100 ppm/°C	330 Ohm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	160 mW	0.09 in	150 °C	-55 °C	8	2 %
Vishay Dale SOMC1605191AGEA	0.22 in	0.44 in	Dual Terminator	100 ppm/°C	330 Ohm 470 Ohm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	80 mW	0.09 in	150 °C	-55 °C	28	2 %
Vishay Dale SOMC16031K80GEA	0.22 in	0.44 in	Isolated	100 ppm/°C	1.8 kOhm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	160 mW	0.09 in	150 °C	-55 °C	8	2 %
Vishay Dale SOMC160118K0GEA	0.22 in	0.44 in	Bussed	100 ppm/°C	18 kOhm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	80 mW	0.09 in	150 °C	-55 °C	15	2 %
Vishay Dale SOMC160322R0GEA	0.22 in	0.44 in	Isolated	100 ppm/°C	22 Ohm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	160 mW	0.09 in	150 °C	-55 °C	8	2 %
Vishay Dale SOMC140310K0GEA	0.22 in	0.39 in	Isolated	100 ppm/°C	10 kOhm	5.59 mm	14-SOIC	0.22 "	Surface Mount	14 pins	160 mW	0.09 in	150 °C	-55 °C	7	2 %
Vishay Dale SOMC14013K30GEA	0.22 in	0.39 in	Bussed	100 ppm/°C	3.3 kOhm	5.59 mm	14-SOIC	0.22 "	Surface Mount	14 pins	80 mW	0.09 in	150 °C	-55 °C	13	2 %
Vishay Dale SOMC200310K0GEA	0.22 in	0.54 in	Isolated	100 ppm/°C	10 kOhm	5.59 mm	20-SOIC	0.22 "	Surface Mount	20	160 mW	0.09 in	150 °C	-55 °C	10	2 %
Vishay Dale SOMC160327K0GEA	0.22 in	0.44 in	Isolated	100 ppm/°C	27 kOhm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	160 mW	0.09 in	150 °C	-55 °C	8	2 %
Vishay Dale SOMC16033K30GEA	0.22 in	0.44 in	Isolated	100 ppm/°C	3.3 kOhm	5.59 mm	16-SOIC	0.22 "	Surface Mount	16	160 mW	0.09 in	150 °C	-55 °C	8	2 %
