M12A-10PMMS Series

Catalog

M SERIES SENSOR CONNECTOR, M12, A CODE, METAL, 1.5A, 10 PINS, MALE CONNECTOR, MALE CONTACT, HEXAGONAL, SCREW THREAD, SOLDER, REC

Part	Termination	Mounting Feature	Contact Material	Fastening Type	Color	Current Rating	Shell Size - Insert	Contact Finish - Mating	Operating Temperature (Max)	Operating Temperature (Min)	Shielding	Primary Material	Number of Positions	Voltage Rating	Voltage Rating (Type)	Ingress Protection Description	Ingress Protection IP Rating	Insert Material	Mounting Type	Shell Finish	Connector Type	Orientation	Shell Material
McGill Microwave Systems M12A-10PMMS-SF8C15	Wire Leads	Bulkhead Front Side Nut	Copper Alloy	Threaded	Silver	1.5 A	M12-10	Gold	85 °C	-25 °C	Shielded	Metal	12	30 V	AC DC	Dust Tight Water Resistant Waterproof	IP68 IP69K	Glass Filled Nylon PA Polyamide	Panel Mount	Nickel	Male Pins Plug	A	Zinc Alloy
McGill Microwave Systems M12A-10PMMS-SH8B15	Wire Leads	Bulkhead Rear Side Nut	Copper Alloy	Threaded	Silver	1.5 A	M12-10	Gold	85 °C	-25 °C	Shielded	Metal	12	30 V	AC DC	Dust Tight Water Resistant Waterproof	IP68 IP69K	Glass Filled Nylon PA Polyamide	Panel Mount	Nickel	Male Pins Plug	A	Zinc Alloy
McGill Microwave Systems M12A-10PMMS-SF8B15	Wire Leads	Bulkhead Front Side Nut	Copper Alloy	Threaded	Silver	1.5 A	M12-10	Gold	85 °C	-25 °C	Shielded	Metal	12	30 V	AC DC	Dust Tight Water Resistant Waterproof	IP68 IP69K	Glass Filled Nylon PA Polyamide	Panel Mount	Nickel	Male Pins Plug	A	Zinc Alloy
McGill Microwave Systems M12A-10PMMS-SH8002	Solder Cup	Bulkhead Rear Side Nut	Copper Alloy	Threaded	Silver	1.5 A	M12-10	Gold	105 °C	-40 °C	Shielded	Metal	10	30 V	AC DC	Dust Tight Water Resistant Waterproof	IP68 IP69K	Glass Filled Nylon PA Polyamide	Panel Mount	Nickel	Male Pins Receptacle	A	Zinc Alloy
