ADL5544 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
RF AMPLIFIER, 30MHZ TO 6GHZ, 14.5 DB GAIN, SOT-89-3, -40 °C TO 105 °C
| Part | Mounting Type | Noise Figure | RF Type | P1dB | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Package / Case | Current - Supply | Frequency Range 1 (Max) | Frequency Range 1 (Min) | Package Name | Test Frequency | Gain | Supplied Contents | For Use With/Related Products | Type | Utilized IC / Part | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Surface Mount | 2.9 dB | General Purpose | 17.6 dBm | 5.25 V | 4.75 V | TO-243AA | 55 mA | 6 GHz | 30 MHz | SOT-89-3 | 900 MHz | 17.4 dB | |||||
 Analog Devices Inc./Maxim Integrated | 6 GHz | 30 MHz | Board(s) | ADL5544 | Amplifier | ADL5544 | Board |
