ADM1278 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

HOT SWAP CONTROLLER AND DIGITAL POWER AND ENERGY MONITOR WITH PMBUS INTERFACE

Part	Number of Channels	Type	Package Length	Package Name	Package Width	Package / Case	Applications	Mounting Type	Programmable Features	Current - Supply	Operating Temperature (Min)	Operating Temperature (Max)	Features	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Internal Switch(s)
Analog Devices Inc./Maxim Integrated ADM1278-1BCPZ-RL	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-1ACPZ	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-3ACPZ-RL	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-2ACPZ-RL	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-1AACPZ	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-1BCPZ	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-2ACPZ	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-3ACPZ	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-1ACPZ-RL	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
Analog Devices Inc./Maxim Integrated ADM1278-1AACPZ-RL	1	Hot Swap Controller Monitor	5 mm	32-LFCSP	5 mm	32-WFQFN Exposed Pad CSP	General Purpose	Surface Mount	Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO	5.5 mA	-40 °C	85 °C	PMBus	4.5 V	20 V	No
