ADCMP394 Series

Catalog

SINGLE COMPARATOR WITH ACCURATE REFERENCE OUTPUT

Part	Hysteresis	Package Name	Propagation Delay (Max)	Mounting Type	Supply Configuration	Voltage - Supply (Single) Minimum	Voltage - Supply (Single) Maximum	Current - Quiescent (Max)	Voltage - Input Offset (Max)	Type	Output Type	Package Length	Package Width	Current - Input Bias (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Number of Elements	CMRR (Typ)	PSRR (Typ)
Analog Devices Inc./Maxim Integrated ADCMP394ARZ-RL7	4 mV	8-SOIC	4.2 µs	Surface Mount	Dual Single	2.3 V	5.5 V	47.9 µA	5 mV	General Purpose Standard (General Purpose)	Open-Drain	0.154 in	3.9 mm	0.03 µA	125 °C	-40 °C	1	74 dB	80 dB
Analog Devices Inc./Maxim Integrated ADCMP394ARZ	4 mV	8-SOIC	4.2 µs	Surface Mount	Dual Single	2.3 V	5.5 V	47.9 µA	5 mV	General Purpose Standard (General Purpose)	Open-Drain	0.154 in	3.9 mm	0.03 µA	125 °C	-40 °C	1	74 dB	80 dB
