ADL8121 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
GAAS, PHEMT, MMIC, LOW NOISE AMPLIFIER, 0.025 GHZ TO 12 GHZ
| Part | Package Name | Package Width | Package Length | Mounting Type | Package / Case | Noise Figure | Frequency (Max) | Frequency (Min) | P1dB | Voltage - Supply | Current - Supply | Test Frequency (Maximum) | Test Frequency (Minimum) | RF Type | Gain | For Use With/Related Products | Supplied Contents | Utilized IC / Part | Contents | Type | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 6-LFCSP | 2 mm | 2 mm | Surface Mount | 6-VDFN Exposed Pad CSP | 3.5 dB | 12 GHz | 25 MHz | 17 dBm | 5 VDC | 95 mA | 12 GHz | 10 GHz | Radar | 17 dB | |||||||
 Analog Devices Inc./Maxim Integrated | 12 GHz | 25 MHz | ADL8121 | Board(s) | ADL8121 | Board | Amplifier | |||||||||||||||
Analog Devices Inc./Maxim Integrated | 6-LFCSP | 2 mm | 2 mm | Surface Mount | 6-VDFN Exposed Pad CSP | 3.5 dB | 12 GHz | 25 MHz | 21 dBm | 95 mA | 10 GHz | 25 MHz | Radar | 17 dB | 2 V | 6 V |
