ADG1439 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
±15 V/+12 V/±5 V, DUAL 4 TO 1 MULTIPLEXER, SERIALLY CONTROLLED MATRIX SWITCH
| Part | Channel Capacitance (CS(off)) | Channel Capacitance (CD(off)) | Voltage - Supply, Dual (Minimum) | Voltage - Supply, Dual (Nominal) | Voltage - Supply, Dual (Maximum) | Package Length | Package Name | Package Width | Channel-to-Channel Matching (ΔRon) | On-State Resistance (Max) | Crosstalk | Switch Circuit Type | -3db Bandwidth | Number of Circuits | Current - Leakage (Max) | Operating Temperature (Max) | Operating Temperature (Min) | Package / Case | Voltage - Supply, Single (V+) (Maximum) | Voltage - Supply, Single (V+) (Minimum) | Demultiplexer Outputs | Multiplexer Inputs | Mounting Type | Charge Injection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 9 pF | 28 pF | -4.5 V | 4.5 V | 16.5 V | 4 mm | 20-LFCSP | 4 mm | 550 mOhm | 11.5 Ohms | -70 dB | SP4T | 130 MHz | 2 | 150 pA | 125 °C | -40 °C | 20-WFQFN Exposed Pad CSP | 16.5 V | 5 V | 1 | 4 | Surface Mount | 4 pC |
 Analog Devices Inc./Maxim Integrated | 9 pF | 28 pF | -4.5 V | 4.5 V | 16.5 V | 0.173 in | 20-TSSOP | 4.4 mm | 550 mOhm | 11.5 Ohms | -70 dB | SP4T | 130 MHz | 2 | 150 pA | 125 °C | -40 °C | 16.5 V | 5 V | 1 | 4 | Surface Mount | 4 pC | |
Analog Devices Inc./Maxim Integrated | 9 pF | 28 pF | -4.5 V | 4.5 V | 16.5 V | 0.173 in | 20-TSSOP | 4.4 mm | 550 mOhm | 11.5 Ohms | -70 dB | SP4T | 130 MHz | 2 | 150 pA | 125 °C | -40 °C | 16.5 V | 5 V | 1 | 4 | Surface Mount | 4 pC |
