FA1-NESP Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN SMB 0HZ TO 4GHZ 50OHM CRIMP ST CABLE MOUNT PL GOLD OVER NICKEL TRAY
| Part | Fastening Type | Shield Termination | Mounting Type | Cable Group | Frequency - Max | Impedance | Connector Style | Connector Type | Center Contact Material | Features - Code | Features | Housing Color | Contact Termination | Number of Ports | Mounting Feature | Mating Cycles | Body Finish | Insertion Loss | Includes Total Count | Includes | Center Contact Plating | Operating Temperature (Max) | Operating Temperature (Min) | Body Material | Dielectric Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Locking Ramp | Crimp | Panel Mount | 141 303 58A 58B 58C 9907 Belden B7806A LMR-195 RG-58 | 4 GHz | 50 Ohm | Fakra SMB | Male Pin Plug | Brass | E | Code E | Green Leaf | Crimp | 1 | Flange | 100 cycles | Nickel | 0.3 dB | 3 pcs | Connector Contact Ferrule | Gold | 100 °C | -40 °C | Brass | Polytetrafluoroethylene (PTFE) |
 McGill Microwave Systems | Locking Ramp | Solder | Through Hole | 6000 MHz | 50 Ohm | Fakra SMB | Male Pin Plug | Brass | E | Code E | Green Leaf | Solder | 1 | 100 cycles | Gold | Gold | 100 °C | -40 °C | Brass | Polytetrafluoroethylene (PTFE) | |||||
 McGill Microwave Systems | Locking Ramp | Solder | Board Edge Cutout Right Angle Surface Mount Through Hole | 4 GHz | 50 Ohm | Fakra SMB | Male Pin Plug | Brass | E | Code E | Green Leaf | Solder | 1 | 100 cycles | Gold | 0.3 dB | Gold | 100 °C | -40 °C | Brass | Polytetrafluoroethylene (PTFE) | ||||
 McGill Microwave Systems | Locking Ramp | Solder | Through Hole | 4 GHz | 50 Ohm | Fakra SMB | Male Pin Plug | Brass | E | Code E | Green Leaf | Solder | 1 | 100 cycles | Gold | Gold | 85 °C | -40 °C | Brass | Polytetrafluoroethylene (PTFE) |
