TFPT Series

Catalog

PTC THERMISTORS PTC 470OHMS 1% LINEAR

Part	Resistance Tolerance (%)	Resistance	Mounting Type	Power - Max	Package Name	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)	Package Length	Package Width
Vishay Dale TFPT0805L4700FM	1 %	470 Ohms	Surface Mount	100 mW	0805	0805 (2012 Metric)	125 °C	-55 °C
Vishay Dale TFPT0603L8200FV	1 %	820 Ohms	Surface Mount	75 mW	0603	0603 (1608 Metric)	125 °C	-55 °C
Vishay Dale TFPT1206L3301FM	1 %	3.3 kOhms	Surface Mount	125 mW	1206	1206 (3216 Metric)	125 °C	-55 °C
Vishay Dale TFPT1206L5601FM	1 %	5.6 kOhms	Surface Mount	125 mW	1206 (3216 Metric)	1206 (3216 Metric)	150 °C	-55 °C
Vishay Dale TFPT1206L1500JV	5 %	150 Ohms	Surface Mount	125 mW	1206 (3216 Metric)	1206 (3216 Metric)	150 °C	-55 °C
Vishay Dale TFPT0805L2201FM	1 %	2.2 kOhms	Surface Mount	100 mW	0805	0805 (2012 Metric)	125 °C	-55 °C
Vishay Dale TFPT0603L3300FV	1 %	330 Ohms	Surface Mount	75 mW	0603	0603 (1608 Metric)	125 °C	-55 °C
Vishay Dale TFPT0805L1201FM	1 %	1.2 kOhms	Surface Mount	100 mW	0805 0805 (2012 Metric)	0805 (2012 Metric)	150 °C	-55 °C	2 mm	1.2 mm
Vishay Dale TFPT0805L5001JV	5 %	5 kOhms	Surface Mount	100 mW	0805	0805 (2012 Metric)	125 °C	-55 °C
Vishay Dale TFPT1206L2200FM	1 %	220 Ohms	Surface Mount	125 mW	1206	1206 (3216 Metric)	125 °C	-55 °C
