XCV600E Series

Catalog

IC FPGA 444 I/O 676FCBGA

Part	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Number of LABs/CLBs	Number of Logic Elements/Cells	Number of I/O	Package / Case	Total RAM Bits	Mounting Type	Package Length	Package Name	Package Width	Number of Gates	Operating Temperature (Max)	Operating Temperature (Min)
AMD / Xilinx XCV600E-8FG676C	1.89 V	1.71 V	3456	15552	444	676-BGA	294912 bits	Surface Mount	27 mm	676-FBGA	27 mm	985882	85 °C	0 °C
AMD / Xilinx XCV600E-7BG432I	1.89 V	1.71 V	3456	15552	316	432-LBGA Exposed Pad Metal	294912 bits	Surface Mount	40 mm	432-MBGA	40 mm	985882	100 °C	-40 °C
AMD / Xilinx XCV600E-7FG900I	1.89 V	1.71 V	3456	15552	512	900-BBGA	294912 bits	Surface Mount	31 mm	900-FBGA	31 mm	985882	100 °C	-40 °C
AMD / Xilinx XCV600E-6FG676I	1.89 V	1.71 V	3456	15552	444	676-BGA	294912 bits	Surface Mount	27 mm	676-FBGA	27 mm	985882	100 °C	-40 °C
AMD / Xilinx XCV600E-7BG432C0773	1.89 V	1.71 V	3456	15552	316	432-LBGA Exposed Pad	294912 bits	Surface Mount	40 mm	432-MBGA	40 mm	985882	85 °C	0 °C
AMD / Xilinx XCV600E-6HQ240C	1.89 V	1.71 V	3456	15552	158	240-BFQFP Exposed Pad	294912 bits	Surface Mount	32 mm	240-PQFP	32 mm	985882	85 °C	0 °C
AMD / Xilinx XCV600E-6BG432I	1.89 V	1.71 V	3456	15552	316	432-LBGA Exposed Pad Metal	294912 bits	Surface Mount	40 mm	432-MBGA	40 mm	985882	100 °C	-40 °C
AMD / Xilinx XCV600E-8BG432C	1.89 V	1.71 V	3456	15552	316	432-LBGA Exposed Pad Metal	294912 bits	Surface Mount	40 mm	432-MBGA	40 mm	985882	85 °C	0 °C
AMD / Xilinx XCV600E-7BG432C	1.89 V	1.71 V	3456	15552	316	432-LBGA Exposed Pad Metal	294912 bits	Surface Mount	40 mm	432-MBGA	40 mm	985882	85 °C	0 °C
AMD / Xilinx XCV600E-6BG560C	1.89 V	1.71 V	3456	15552	404	560-LBGA Exposed Pad Metal	294912 bits	Surface Mount	42.5 mm	560-MBGA	42.5 mm	985882	85 °C	0 °C
