SF3211 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
SMPM MALE THREAD-IN CONNECTOR (.012"), FD" /INDIVIDUAL - TRAY (PACK FILL QTY: 100)
| Part | Shield Termination | Fastening Type | Contact Termination | Mounting Type | Number of Ports | Frequency - Max | Center Contact Material | Impedance | Housing Color | Connector Style | Connector Type | Features | Dielectric Material | Center Contact Plating | Operating Temperature (Max) | Operating Temperature (Min) | Mating Cycles | Body Material | Insertion Loss | Mounting Feature | Cable Group Diameter (Default) | Cable Group | Body Finish | Contact Finish | Pin or Socket | Wire Gauge | Wire Gauge (Diameter) | Contact Material | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Solder | Snap-On | Solder | Panel Mount Threaded | 1 | 40 Gbps | Beryllium Copper | 50 Ohm | Silver | SMPM | Male Pin Plug | Extended Insulation Full Detent | Polytetrafluoroethylene (PTFE) | Gold | 125 °C | -55 °C | 100 cycles | Stainless Steel | |||||||||||
 McGill Microwave Systems | Screw | Threaded | Compression | Surface Mount | 1 | 65 GHz | Beryllium Copper | 50 Ohm | SMPM | Male Pin Plug | Flange | Polychlorotrifluoroethylene (PCTFE) | Gold | 165 °C | -65 °C | Stainless Steel | 0.56 dB | Flange | |||||||||||
 McGill Microwave Systems | Screw | Threaded | Compression | Surface Mount | 1 | 65 GHz | Beryllium Copper | 50 Ohm | SMPM | Male Pin Plug | Flange | Polychlorotrifluoroethylene (PCTFE) | Gold | 165 °C | -65 °C | Stainless Steel | 0.56 dB | Flange | |||||||||||
 McGill Microwave Systems | Screw | Threaded | Compression | Surface Mount | 1 | 65 GHz | Beryllium Copper | 50 Ohm | SMPM | Male Pin Plug | Flange | Polychlorotrifluoroethylene (PCTFE) | Gold | 165 °C | -65 °C | Stainless Steel | 0.56 dB | Flange | |||||||||||
 McGill Microwave Systems | Solder | Snap-On | Solder | Through Hole | 1 | 20 Gbps | Brass | 50 Ohm | Silver | SMPM | Male Pin Plug | Smooth Bore | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel | ||||||||||||||
 McGill Microwave Systems | Solder | Snap-On | Solder | Panel Mount | 1 | 40 Gbps | Beryllium Copper | 50 Ohm | Gold | SMPM | Male Pin Plug | Full Detent | Polytetrafluoroethylene (PTFE) | Gold | 125 °C | -55 °C | 100 cycles | Stainless Steel | Flange | 0.085 in | RG-405 | Gold | |||||||
 McGill Microwave Systems | Solder | Gold | Assembly Coax Pin Center | Flexible | 0.085 in | Beryllium Copper | Coaxial | ||||||||||||||||||||||
 McGill Microwave Systems | Solder | Snap-On | Solder | Panel Mount Threaded | 1 | 40 Gbps | Beryllium Copper | 50 Ohm | Silver | SMPM | Male Pin Plug | Extended Insulation Full Detent | Polytetrafluoroethylene (PTFE) | Gold | 125 °C | -55 °C | 100 cycles | Stainless Steel | |||||||||||
 McGill Microwave Systems | Solder | Snap-On | Solder | Panel Mount | 1 | 40 Gbps | Beryllium Copper | 50 Ohm | Silver | SMPM | Male Pin Plug | Smooth Bore | Polytetrafluoroethylene (PTFE) | Gold | 125 °C | -55 °C | 500 cycles | Stainless Steel | Flange | 0.085 in | RG-405 | ||||||||
 McGill Microwave Systems | Solder | Snap-On | Solder | Through Hole | 1 | 20 Gbps | Brass | 50 Ohm | Silver | SMPM | Male Pin Plug | Full Detent | Polytetrafluoroethylene (PTFE) | Gold | Stainless Steel |
