ADM7154 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
600 MA, ULTRALOW NOISE, HIGH PSRR, RF LINEAR REGULATOR
| Part | Package / Case | Number of Regulators | Current - Quiescent (Iq) | Voltage - Input (Max) | Output Configuration | Voltage - Output (Min/Fixed) | Output Type | Control Features | Current - Supply (Max) | Package Length | Package Name | Package Width | Voltage Dropout (Max) | Mounting Type | Current - Output | Protection Features | Operating Temperature (Max) | Operating Temperature (Min) | PSRR | Package Features | Board Type | Supplied Contents | Regulator Type | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Voltage - Output | Voltage - Input (Minimum) | Voltage - Input (Maximum) | Contents | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 8-WFDFN Exposed Pad CSP | 1 | 7 mA | 5.5 V | Positive | 3.3 V | Fixed | Enable | 10 mA | 3 mm | 8-LFCSP-WD | 3 mm | 0.21 V | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | 58 dB | ||||||||||||
 Analog Devices Inc./Maxim Integrated | 1 | 7 mA | 5.5 V | Positive | 1.8 V | Fixed | Enable | 10 mA | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | 63 dB | Exposed Pad | |||||||||||||
 Analog Devices Inc./Maxim Integrated | 1 | 7 mA | 5.5 V | Positive | 3 V | Fixed | Enable | 10 mA | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | Exposed Pad | ||||||||||||||
 Analog Devices Inc./Maxim Integrated | 600 mA | Fully Populated | Board(s) | Positive Fixed | 1 | Single | 1 | 3.3 V | 2.3 V | 5.5 V | Board | ADM7154 | |||||||||||||||||||
Analog Devices Inc./Maxim Integrated | 8-WFDFN Exposed Pad CSP | 1 | 7 mA | 5.5 V | Positive | 1.8 V | Fixed | Enable | 10 mA | 3 mm | 8-LFCSP-WD | 3 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | 63 dB | |||||||||||||
Analog Devices Inc./Maxim Integrated | 1 | 7 mA | 5.5 V | Positive | 2.8 V | Fixed | Enable | 10 mA | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | Exposed Pad | ||||||||||||||
Analog Devices Inc./Maxim Integrated | 8-WFDFN Exposed Pad CSP | 1 | 7 mA | 5.5 V | Positive | 2.8 V | Fixed | Enable | 10 mA | 3 mm | 8-LFCSP-WD | 3 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | ||||||||||||||
 Analog Devices Inc./Maxim Integrated | 8-WFDFN Exposed Pad CSP | 1 | 7 mA | 5.5 V | Positive | 2.5 V | Fixed | Enable | 10 mA | 3 mm | 8-LFCSP-WD | 3 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | ||||||||||||||
Analog Devices Inc./Maxim Integrated | 8-WFDFN Exposed Pad CSP | 1 | 7 mA | 5.5 V | Positive | 3 V | Fixed | Enable | 10 mA | 3 mm | 8-LFCSP-WD | 3 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | ||||||||||||||
Analog Devices Inc./Maxim Integrated | 1 | 7 mA | 5.5 V | Positive | 1.2 V | Fixed | Enable | 10 mA | 0.154 in | 8-SOIC 8-SOIC-EP | 3.9 mm | Surface Mount | 600 mA | Over Current Over Temperature | 125 °C | -40 °C | Exposed Pad |
