ADL8140 Series

10 GHz to 18 GHz Low Noise Amplifier

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

10 GHz to 18 GHz Low Noise Amplifier

Part	Current - Supply	Test Frequency (Minimum)	Test Frequency (Maximum)	Frequency (Min)	Frequency (Max)	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Package Length	Package Name	Package Width	RF Type	Package / Case	Noise Figure	P1dB	Mounting Type	Gain
Analog Devices Inc./Maxim Integrated ADL8140ACPZN-R7	33.3 mA	15 GHz	18 GHz	10 GHz	18 GHz	3.5 V	1.2 V	2 mm	8-LFCSP	2 mm	Radar	8-VFDFN Exposed Pad CSP	1.1 dB	8.5 dBm	Surface Mount	28 dB
Analog Devices Inc./Maxim Integrated ADL8140ACPZN	35 mA	15 GHz	18 GHz	10 GHz	18 GHz	3.5 V	1.2 V	2 mm	8-LFCSP	2 mm	Radar	8-VFDFN Exposed Pad CSP	1.1 dB	8.5 dBm	Surface Mount	28 dB

Catalog

10 GHz to 18 GHz Low Noise Amplifier

Description

The ADL8140 is a low noise amplifier (LNA) that operates from 10 GHz to 18 GHz.Typical gain and noise figure are 27.5 dB and 1 dB, respectively, from 12 GHz to 15 GHz. Output power for 1 dB compression (OP1dB) and output third-order intercept (OIP3), are 8 dBm and 23 dBm, respectively, from 12 GHz to 15 GHz. The nominal quiescent current (IDQ), which can be adjusted, is 35 mA from a 1.5 V supply voltage (VDD). The ADL8140 also features inputs/outputs that are AC-coupled and internally matched to 50 Ω.The ADL8140 is housed in a RoHS-compliant, 2 mm × 2 mm, 8-lead lead frame chip scale package [LFCSP] and is specified for operation from −55°C to +125°C.
