ADG732 Series

Catalog

32-CHANNEL, 4 Ω 1.8 V TO 5.5 V, ±2.5 V, ANALOG MULTIPLEXER

Part	-3db Bandwidth	Voltage - Supply, Dual (Maximum)	Voltage - Supply, Dual (Minimum)	Demultiplexer Outputs	Multiplexer Inputs	Mounting Type	Current - Leakage (Max)	Channel Capacitance (CS(off))	Channel Capacitance (CD(off))	Charge Injection	Voltage - Supply, Single (V+) (Minimum)	Voltage - Supply, Single (V+) (Maximum)	Number of Circuits	Package Width	Package Name	Package Length	On-State Resistance (Max)	Crosstalk	Package / Case	Operating Temperature (Max)	Operating Temperature (Min)
Analog Devices Inc./Maxim Integrated ADG732BCPZ-REEL	18 MHz	2.5 V	-2.5 V	1	32	Surface Mount	250 pA	13 pF	275 pF	1 pC	1.8 V	5.5 V	1	7 mm	48-LFCSP	7 mm	5.5 Ohm	-72 dB	48-WFQFN Exposed Pad CSP	125 °C	-40 °C
Analog Devices Inc./Maxim Integrated ADG732BSUZ	18 MHz	2.5 V	-2.5 V	1	32	Surface Mount	250 pA	13 pF	275 pF	1 pC	1.8 V	5.5 V	1	7 mm	48-TQFP	7 mm	5.5 Ohm	-72 dB	48-TQFP	125 °C	-40 °C
Analog Devices Inc./Maxim Integrated ADG732BCPZ	18 MHz	2.5 V	-2.5 V	1	32	Surface Mount	250 pA	13 pF	275 pF	1 pC	1.8 V	5.5 V	1	7 mm	48-LFCSP	7 mm	5.5 Ohm	-72 dB	48-WFQFN Exposed Pad CSP	125 °C	-40 °C
Analog Devices Inc./Maxim Integrated ADG732BSUZ-REEL	18 MHz	2.5 V	-2.5 V	1	32	Surface Mount	250 pA	13 pF	275 pF	1 pC	1.8 V	5.5 V	1	7 mm	48-TQFP	7 mm	5.5 Ohm	-72 dB	48-TQFP	125 °C	-40 °C
