V705 Series

Catalog

CONNECTOR: PLUGGABLE TERMINAL BLOCK; SOCKET; FEMALE; 8A; 300V

Part	Pitch	Termination Style	Color	Header Orientation Angle	Header Orientation	Type	Voltage - UL	Positions Per Level	Number of Positions	Operating Temperature (Min)	Operating Temperature (Max)	Current - UL	Mounting Type	Features	Number of Levels	Contact Mating Finish	Housing Material	Contact Material	Insulation Height	Material Flammability Rating	Contact Tail Length
McGill Microwave Systems V70532510000G	0.15 in	Solder	Green	90 °	Right Angle	Female Sockets Header	300 V	5	5	-40 °C	115 °C	8 A	Through Hole	Mating Flange	1	Tin	Thermoplastic	Phosphor Bronze	0.268 in	UL94 V-0	0.134 in
McGill Microwave Systems V70512510000G	0.138 in	Solder	Green	90 °	Right Angle	Female Sockets Header	300 V	5	5	-40 °C	115 °C	4 A	Through Hole	Mating Flange	1	Tin	Thermoplastic	Phosphor Bronze	0.268 in	UL94 V-0	0.134 in
McGill Microwave Systems V70551500000G	5.08 mm	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	20 A	Through Hole	Retention Latches	1	Tin	Thermoplastic	Copper	0.748 in	UL94 V-0	0.138 in
McGill Microwave Systems V705A1500000G	0.295 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	10 A	Through Hole	Retention Latches	1	Tin	Thermoplastic	Phosphor Bronze	0.748 in	UL94 V-0	0.138 in
McGill Microwave Systems V70532500000G	0.15 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	8 A	Through Hole	Mating Flange	1	Tin	Thermoplastic	Phosphor Bronze	0.571 in	UL94 V-0	0.134 in
McGill Microwave Systems V70531500000G	0.15 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	8 A	Through Hole		1	Tin	Thermoplastic	Phosphor Bronze	0.571 in	UL94 V-0	0.134 in
McGill Microwave Systems V705A2500000G	0.295 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	10 A	Through Hole	Mating Flange Retention Latches	1	Tin	Thermoplastic	Phosphor Bronze	0.748 in	UL94 V-0	0.138 in
McGill Microwave Systems V70571500000G	0.197 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	10 A	Through Hole	Retention Latches	1	Tin	Thermoplastic	Phosphor Bronze	0.748 in	UL94 V-0	0.138 in
McGill Microwave Systems V70512500000G	0.138 in	Solder	Green		Vertical	Female Sockets Header	300 V	5	5	-40 °C	115 °C	4 A	Through Hole	Mating Flange	1	Tin	Thermoplastic	Phosphor Bronze	0.571 in	UL94 V-0	0.134 in
McGill Microwave Systems V70551510000G	5.08 mm	Solder	Green	90 °	Right Angle	Female Sockets Header	300 V	5	5	-40 °C	115 °C	20 A	Through Hole	Retention Latches	1	Tin	Thermoplastic	Copper		UL94 V-0	0.138 in
