PRF18 Series
Manufacturer: Samtec Inc.
Beta
⌘K
RF CONNECTORS / COAXIAL CONNECTORS 1.84MM BULKHEAD JACK RG405, SOLDER CLAMP
| Part | Dielectric Material | Center Contact Plating | Body Material | Shield Termination | Center Contact Material | Impedance | Contact Termination | Number of Ports | Connector Type | Cable Group Diameter (Semi Rigid) | Cable Group | Mounting Type | Connector Plug Diameter | Mounting Feature | Fastening Type | Housing Color | Frequency - Max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Samtec Inc. | Polyetherimide (PEI) | Gold | Stainless Steel | Clamp | Beryllium Copper | 50 Ohm | Solder | 1 | Female Socket Jack | 0.085 in | RG-405 | Panel Mount | 1.85 mm | Bulkhead Front Side Nut | Threaded | Silver | 65 GHz |
