ADIN1300 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

EVALUATION KIT, ADIN1300, ETHERNET PHYSICAL LAYER DEVICE, 10 & 100 MBPS & 1 GBPS, ROBUST, INDUSTRIAL

Part	Supplied Contents	Contents	Type	Function	Primary Attributes	Protocol	Duplex	Package / Case	Package Width	Package Name	Package Length	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Supply (Range 1 Minimum)	Voltage - Supply (Range 2 Maximum)	Voltage - Supply (Range 2 Minimum)	Voltage - Supply (Range 1 Maximum)	Voltage - Supply (Range 3 Minimum)	Voltage - Supply (Range 3 Maximum)	Number of Receivers	Number of Drivers	Data Rate	Data Rate	Mounting Type
Analog Devices Inc./Maxim Integrated EVAL-ADIN1300FMCZ	Board(s)	Board	Interface	Ethernet PHY	Single Chip Hi-Speed USB to 10/100 Ethernet
Analog Devices Inc./Maxim Integrated ADIN1300BCPZ			Transceiver			IEEE 802.3	Full Half	40-WFQFN Exposed Pad CSP	6 mm	40-LFCSP-WQ	6 mm	85 °C	-40 °C	1.71 V	2.75 V	2.25 V	1.89 V	3.14 V	3.46 V	4	4	10 Mbps 100 Mbps 1000 Mbps	100Mbps 10Mbps 1Gbps	Surface Mount
Analog Devices Inc./Maxim Integrated ADIN1300CCPZ			Transceiver			IEEE 802.3	Full Half	40-WFQFN Exposed Pad CSP	6 mm	40-LFCSP-WQ	6 mm	105 °C	-40 °C	1.71 V	2.75 V	2.25 V	1.89 V	3.14 V	3.46 V	4	4	10 Mbps 100 Mbps 1000 Mbps	100Mbps 10Mbps 1Gbps	Surface Mount
Analog Devices Inc./Maxim Integrated ADIN1300BCPZ-R7			Transceiver			IEEE 802.3	Full Half	40-WFQFN Exposed Pad CSP	6 mm	40-LFCSP-WQ	6 mm	85 °C	-40 °C	1.71 V	2.75 V	2.25 V	1.89 V	3.14 V	3.46 V	4	4	10 Mbps 100 Mbps 1000 Mbps	100Mbps 10Mbps 1Gbps	Surface Mount
Analog Devices Inc./Maxim Integrated ADIN1300CCPZ-R7			Transceiver			IEEE 802.3	Full Half	40-WFQFN Exposed Pad CSP	6 mm	40-LFCSP-WQ	6 mm	105 °C	-40 °C	1.71 V	2.75 V	2.25 V	1.89 V	3.14 V	3.46 V	4	4	10 Mbps 100 Mbps 1000 Mbps	100Mbps 10Mbps 1Gbps	Surface Mount
