AD9956 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
IC DDS 3GHZ 14BIT 48LFCSP
| Part | Master fclk | Operating Temperature (Max) | Operating Temperature (Min) | Package Width | Package Name | Package Length | Resolution (Bits) | Mounting Type | Package / Case | Tuning Word Width (Bits) | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Supplied Contents | Function | Utilized IC / Part | Type | Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 3 GHz | 125 °C | -40 °C | 7 mm | 48-LFCSP | 7 mm | 14 b | Surface Mount | 48-WFQFN Exposed Pad CSP | 48 b | 1.96 V | 1.71 V | |||||
 Analog Devices Inc./Maxim Integrated | Board(s) | Direct Digital Synthesis (DDS) | AD9956 | Timing | Board | ||||||||||||
Analog Devices Inc./Maxim Integrated | 3 GHz | 125 °C | -40 °C | 7 mm | 48-LFCSP-VQ | 7 mm | 14 b | Surface Mount | 48-VFQFN Exposed Pad CSP | 48 b | 1.96 V | 1.71 V | |||||
 Analog Devices Inc./Maxim Integrated | Board(s) | Direct Digital Synthesis (DDS) | AD9956 | Timing | Board |
