AD9204 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

ANALOG TO DIGITAL CONVERTER, 10 BIT, 40 MSPS, DIFFERENTIAL, SINGLE ENDED, SPI, SINGLE, 1.7 V

Part	Number of A/D Converters	Number of Inputs	Features	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Package Length	Package Name	Package Width	Configuration	Input Type	Mounting Type	Data Interface	Voltage - Supply, Analog	Operating Temperature (Min)	Operating Temperature (Max)	Reference Type	Ratio - ADC	Ratio - S/H	Sampling Rate (Per Second)	Architecture	Number of Bits	Package / Case	Supplied Contents	Power (Typ)	Contents	Utilized IC / Part	Input Voltage (Min)	Input Voltage (Max)
Analog Devices Inc./Maxim Integrated AD9204BCPZ-40	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	40 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9204BCPZ-80	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	80 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9204BCPZ-65	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	65 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9204-65EBZ	2 count											SPI							65 MHz		10 bits		Board(s)	150.8 mW	Board	AD9204	1 V	2 V
Analog Devices Inc./Maxim Integrated AD9204-20EBZ	2 count											SPI							20 MHz		10 bits		Board(s)	76.7 mW	Board	AD9204	1 V	2 V
Analog Devices Inc./Maxim Integrated AD9204-80EBZ	2 count											SPI							80 MHz		10 bits		Board(s)	177 mW	Board	AD9204	1 V	2 V
Analog Devices Inc./Maxim Integrated AD9204BCPZRL7-65	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	65 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9204BCPZ-20	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	20 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
Analog Devices Inc./Maxim Integrated AD9204-40EBZ	2 count											SPI							40 MHz		10 bits		Board(s)	111 mW	Board	AD9204	1 V	2 V
Analog Devices Inc./Maxim Integrated AD9204BCPZRL7-20	2 count	2	Simultaneous Sampling	3.6 V	1.7 V	9 mm	64-LFCSP-VQ	9 mm	S/H-ADC	Differential Single Ended	Surface Mount	Parallel	1.8 V	-40 °C	85 °C	External Internal	1	1	20 MHz	Pipelined	10 bits	64-VFQFN Exposed Pad CSP
