920-50 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
CONN HD-EFI JACK 50 OHM EDGE MNT
| Part | Center Contact Material | Mounting Type | Impedance | Frequency - Max | Shield Termination | Housing Color | Number of Ports | Fastening Type | Connector Type | Contact Termination | Connector Style | Features | Dielectric Material | Center Contact Plating | Body Material | Operating Temperature (Min) | Operating Temperature (Max) | Mating Cycles | Insertion Loss | Body Finish | Conversion Type | Convert To (Adapter End) | Center Gender | Convert From (Adapter End) | Adapter Type | Style | Adapter Series |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Brass | Board Edge End Launch | 50 Ohm | 6000 MHz | Solder | Gold | 1 | Push-Pull | Female Socket Jack | Solder | EFI HD | Limited Detent | Polytetrafluoroethylene (PTFE) | Gold | Brass | -45 °C | 125 °C | 50 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Brass | Surface Mount | 50 Ohm | 6000 MHz | Solder | Gold | 1 | Push-Pull | Female Socket Jack | Solder | EFI HD | Limited Detent | Liquid Crystal Polymer (LCP) | Gold | Brass | -45 °C | 125 °C | 50 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Brass | Surface Mount | 50 Ohm | 6000 MHz | Solder | Gold | 1 | Push-Pull | Female Socket Jack | Solder | EFI HD | Smooth Bore | Liquid Crystal Polymer (LCP) | Gold | Brass | -45 °C | 125 °C | 200 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Brass | Board Edge End Launch | 50 Ohm | 6000 MHz | Solder | Gold | 1 | Push-Pull | Male Pin Plug | Solder | EFI HD | Smooth Bore | Polytetrafluoroethylene (PTFE) | Gold | Brass | -45 °C | 125 °C | 200 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Brass | Through Hole | 50 Ohm | 6000 MHz | Solder | Gold | 1 | Push-Pull | Male Pin Plug | Solder | EFI HD | Smooth Bore | Liquid Crystal Polymer (LCP) | Gold | Brass | -45 °C | 125 °C | 200 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Brass | Through Hole | 50 Ohm | 3 GHz | Solder | Gold | 1 | Push-Pull | Female Socket Jack | Solder | EFI HD | Limited Detent | Liquid Crystal Polymer (LCP) | Gold | Brass | -45 °C | 125 °C | 50 cycles | 0.1 dB | Nickel | |||||||
 McGill Microwave Systems | Copper Alloy | Free Hanging (In-Line) | 50 Ohm | 6000 MHz | Snap-On | Polyoxymethylene (POM) | Gold | Copper Alloy | -40 °C | 85 °C | 200 cycles | White Bronze | Same Series | EFI Female Socket HD Plug | Female | EFI Female Socket HD Plug | Plug to Plug | Straight | EFI HD HD to EFI |
