ISC Series

Catalog

INDUCTOR,NON-MAGNETIC,27NH,20+% TOL,20-% TOL,1210-CASE

Part	Q	Package Name	Type	Inductance Frequency - Test	Shielding	DC Resistance (DCR) (Max)	Size / Dimension Length	Size / Dimension Width	Package / Case	Inductance	Tolerance	Frequency - Self Resonant	Height - Seated (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Material - Core	Mounting Type	Current Rating
Vishay Dale ISC1210ER27NM	45	1210	Wirewound	50 MHz	Shielded	170 mOhm	0.126 in	0.098 in	1210 (3225 Metric)	27 nH	20 %	1 GHz	0.095 in	125 °C	-55 °C	Non-Magnetic	Surface Mount	610 mA
Vishay Dale ISC1210SYR82K	40	1210	Drum Core Wirewound	25.2 MHz	Shielded	500 mOhm	0.126 in	0.098 in	1210 (3225 Metric)	820 nH	10 %	160 MHz	0.095 in	125 °C	-55 °C	Iron Powder	Surface Mount	0.45 A
Vishay Dale ISC1812ES2R2K	30	1812	Drum Core Wirewound	7.96 MHz	Shielded	460 mOhm	0.177 in	0.126 in	1812 (4532 Metric)	2.2 µH	10 %	80 MHz	0.134 in	125 °C	-55 °C	Iron Powder	Surface Mount	390 mA
Vishay Dale ISC1812ES270K	50	1812	Drum Core Wirewound	2.52 MHz	Shielded	1.56 Ohm	0.177 in	0.126 in	1812 (4532 Metric)	27 µH	10 %	13 MHz	0.134 in	125 °C	-55 °C	Ferrite	Surface Mount	212 mA
Vishay Dale ISC1812RV560K	50	1812	Drum Core Wirewound	2.52 MHz	Shielded	2.34 Ohm	0.177 in	0.126 in	1812 (4532 Metric)	56 µH	10 %	8 MHz	0.134 in	125 °C	-55 °C	Ferrite	Surface Mount	173 mA
Vishay Dale ISC1210ERR82K	40	1210	Drum Core Wirewound	25.2 MHz	Shielded	500 mOhm	0.126 in	0.098 in	1210 (3225 Metric)	820 nH	10 %	160 MHz	0.095 in	125 °C	-55 °C	Iron Powder	Surface Mount	0.45 A
Vishay Dale ISC1812ER330J	50	1812	Drum Core Wirewound	2.52 MHz	Shielded	1.72 Ohm	0.177 in	0.126 in	1812 (4532 Metric)	33 µH	5 %	12 MHz	0.134 in	125 °C	-55 °C	Ferrite	Surface Mount	202 mA
Vishay Dale ISC1812ER470K	50	1812	Drum Core Wirewound	2.52 MHz	Shielded	2.1 Ohm	0.177 in	0.126 in	1812 (4532 Metric)	47 µH	10 %	9 MHz	0.134 in	125 °C	-55 °C	Ferrite	Surface Mount	0.183 A
Vishay Dale ISC1812ES3R3J	30	1812	Drum Core Wirewound	7.96 MHz	Shielded	550 mOhm	0.177 in	0.126 in	1812 (4532 Metric)	3.3 µH	5 %	61 MHz	0.134 in	125 °C	-55 °C	Iron Powder	Surface Mount	357 mA
Vishay Dale ISC1812ES220J	50	1812	Drum Core Wirewound	2.52 MHz	Shielded	1.36 Ohm	0.177 in	0.126 in	1812 (4532 Metric)	22 µH	5 %	14 MHz	0.134 in	125 °C	-55 °C	Iron Powder	Surface Mount	227 mA
