ADM6384 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

MICROPROCESSOR SUPERVISORY CIRCUIT IN 4-LEAD SC70

Part	Package Name	Voltage - Threshold	Type	Number of Voltages Monitored	Operating Temperature (Max)	Operating Temperature (Min)	Output	Reset Timeout (Minimum)	Package / Case	Reset	Mounting Type
Analog Devices Inc./Maxim Integrated ADM6384YKS23D3Z-R7	SC-70-4	2.31 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	140 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS29D1-RL7	SC-70-4	2.93 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	1 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS26D3Z-R7	SC-70-4	2.63 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	140 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS45D3Z-R7	SC-70-4	4.5 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	140 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS31D2Z-R7	SC-70-4	3.08 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	20 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS46D2Z-R7	SC-70-4	4.63 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	20 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS17D3Z-R7	SC-70-4	1.67 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	140 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS23D3-RL7	SC-70-4	2.31 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	140 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS31D1Z-R7	SC-70-4	3.08 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	1 ms	SC-82A SOT-343	Active Low	Surface Mount
Analog Devices Inc./Maxim Integrated ADM6384YKS39D2Z-R7	SC-70-4	3.9 V	Simple Reset/Power-On Reset	1	125 °C	-40 °C	Push-Pull Totem Pole	20 ms	SC-82A SOT-343	Active Low	Surface Mount
