BD-02PMMS Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
STANDARD RECEPTACLE(FRONT)
| Part | Termination | Orientation | Material Flammability Rating | Contact Finish - Mating | Contact Material | Mounting Type | Position Types | Number of Positions | Mounting Feature | Ingress Protection IP Rating | Ingress Protection Description | Shielding | Fastening Type | Current Rating | Shell Size - Insert | Voltage Rating | Voltage Rating (Type) | Operating Temperature (Min) | Operating Temperature (Max) | Shell Material | Primary Material | Insert Material | Connector Type | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | Solder Cup | Keyed | UL94 V-0 | Gold | Copper Alloy | Panel Mount | Data | 2 | Bulkhead Front Side Nut | IP68 | Dust Tight Waterproof | Unshielded | Push-Twist | 5 A | B | 250 V | DC | -40 °C | 105 °C | Thermoplastic | Plastic | Thermoplastic | Male Pins Receptacle | Black |
