ADN2806 Series

Catalog

CDR SONET/SDH 3.3V 32-PIN LFCSP EP T/R

Part	PLL	Input Ratio	Output Ratio	Mounting Type	Package Width	Package Name	Package Length	Input	Output	Number of Circuits	Package / Case	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Frequency - Max	Differential Input	Differential Output	Main Purpose	Operating Temperature (Min)	Operating Temperature (Max)
Analog Devices Inc./Maxim Integrated ADN2806ACPZ-RL7	Yes	1	2	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	CML	LVDS	1	32-WFQFN Exposed Pad CSP	3.6 V	3 V	622 MHz	Yes	Yes	SONET/SDH	-40 °C	85 °C
Analog Devices Inc./Maxim Integrated ADN2806ACPZ	Yes	1	2	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	CML	LVDS	1	32-WFQFN Exposed Pad CSP	3.6 V	3 V	622 MHz	Yes	Yes	SONET/SDH	-40 °C	85 °C
Analog Devices Inc./Maxim Integrated ADN2806ACPZ-500RL7	Yes	1	2	Surface Mount	5 mm	32-LFCSP-WQ	5 mm	CML	LVDS	1	32-WFQFN Exposed Pad CSP	3.6 V	3 V	622 MHz	Yes	Yes	SONET/SDH	-40 °C	85 °C
