AD7872 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

CMOS, COMPLETE 14-BIT SAMPLING ADC WITH SERIAL OUTPUT

Part	Mounting Type	Reference Type	Operating Temperature (Min)	Operating Temperature (Max)	Number of Inputs	Package Length	Package Name	Package Width	Architecture	Sampling Rate (Per Second)	Number of Bits	Number of A/D Converters	Configuration	Ratio - ADC	Ratio - S/H	Voltage - Supply, Digital Tolerance	Voltage - Supply, Digital	Data Interface	Input Type	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)
Analog Devices Inc./Maxim Integrated AD7872BRZ	Surface Mount	Internal	-40 °C	85 °C	1	0.295 in	16-SOIC	7.5 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872BR-REEL	Surface Mount	Internal	-40 °C	85 °C	1	0.295 in	16-SOIC	7.5 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872JRZ	Surface Mount	Internal	0 °C	70 °C	1	0.295 in	16-SOIC	7.5 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872TQ	Through Hole	Internal	-55 °C	125 °C	1	0.3 in	16-CDIP 16-CERDIP	7.62 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872JNZ	Through Hole	Internal	0 °C	70 °C	1	0.3 in	16-DIP 16-PDIP	7.62 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872KRZ-REEL	Surface Mount	Internal	0 °C	70 °C	1	0.295 in	16-SOIC	7.5 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872BRZ-REEL	Surface Mount	Internal	-40 °C	85 °C	1	0.295 in	16-SOIC	7.5 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872ANZ	Through Hole	Internal	-40 °C	85 °C	1	0.3 in	16-DIP 16-PDIP	7.62 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
Analog Devices Inc./Maxim Integrated AD7872JN	Through Hole		0 °C	70 °C		0.3 in	16-DIP 16-PDIP	7.62 mm		83 kHz	14 bits	1 count
Analog Devices Inc./Maxim Integrated AD7872AN	Through Hole	Internal	-40 °C	85 °C	1	0.3 in	16-DIP 16-PDIP	7.62 mm	SAR	83 kHz	14 bits	1 count	S/H-ADC	1	1	5 %	5 V	Parallel SPI	Single Ended	5 V	-5 V
