AD8604 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

DIGITRIM™ RRIO QUAD OP AMP WITH VERY LOW OFFSET VOLTAGE

Part	Current - Input Bias	Operating Temperature (Max)	Operating Temperature (Min)	Amplifier Type	Voltage - Supply Span (Max)	Mounting Type	Package Name	Current - Output / Channel	Slew Rate	Current - Supply	Number of Circuits	Voltage - Input Offset	Gain Bandwidth Product	Output Type	Package Width	Package Length	Voltage - Supply Span (Min)
Analog Devices Inc./Maxim Integrated AD8604ARUZ-REEL	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-TSSOP	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail	4.4 mm	0.173 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604DRUZ	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-TSSOP	50 mA	6 V/µs	750 µA	4	1.3 mV	8.4 MHz	Rail-to-Rail	4.4 mm	0.173 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604DRZ	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-SOIC	50 mA	6 V/µs	750 µA	4	1.3 mV	8.4 MHz	Rail-to-Rail	3.9 mm	0.154 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604DRZ-REEL	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-SOIC	50 mA	6 V/µs	750 µA	4	1.3 mV	8.4 MHz	Rail-to-Rail	3.9 mm	0.154 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604ARQZ	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	16-QSOP 16-SSOP	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail	3.9 mm	0.154 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604WARZ-RL	0.2 pA	125 °C	-40 °C	Standard	5.5 V	Surface Mount	14-SOIC	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail Single Ended	3.9 mm	0.154 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604ARUZ	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-TSSOP	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail	4.4 mm	0.173 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604DRUZ-REEL	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-TSSOP	50 mA	6 V/µs	750 µA	4	1.3 mV	8.4 MHz	Rail-to-Rail	4.4 mm	0.173 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604ARZ	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-SOIC	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail	3.9 mm	0.154 in	2.7 V
Analog Devices Inc./Maxim Integrated AD8604ARZ-REEL7	0.2 pA	125 °C	-40 °C	CMOS	5.5 V	Surface Mount	14-SOIC	50 mA	6 V/µs	750 µA	4	80 µV	8.4 MHz	Rail-to-Rail	3.9 mm	0.154 in	2.7 V
