ADA4530-1 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
OPERATIONAL AMPLIFIER, 1 CHANNELS, 2 MHZ, 1.4 V/ΜS, 4.5V TO 16V, ± 2.25V TO ± 8V, NSOIC, 8 PINS
| Part | Current - Input Bias | Package Length | Package Name | Package Width | -3db Bandwidth | Slew Rate | Amplifier Type | Voltage - Supply Span (Max) | Voltage - Input Offset | Current - Supply | Number of Circuits | Output Type | Current - Output / Channel | Operating Temperature (Max) | Operating Temperature (Min) | Gain Bandwidth Product | Voltage - Supply Span (Min) | Mounting Type | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Contents | Utilized IC / Part | Supply Configuration | Voltage - Supply (Dual) Maximum (Magnitude) | Voltage - Supply (Single) Minimum | Voltage - Supply (Single) Maximum | Voltage - Supply (Dual) Minimum (Magnitude) | Current - Supply (Main IC) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 0.02 pA | 0.154 in | 8-SOIC | 3.9 mm | 5.5 MHz | 1.4 V/µs | General Purpose | 16 V | 8 µV | 900 µA | 1 | Rail-to-Rail | 15 mA | 125 °C | -40 °C | 2 MHz | 4.5 V | Surface Mount | |||||||||||
 Analog Devices Inc./Maxim Integrated | 1.4 V/µs | Transimpedance | Rail-to-Rail Single-Ended | 15 mA | 2 MHz | 1 | Single | 1 | Board | ADA4530-1 | Dual Single | 8 V | 4.5 V | 16 V | 2.25 V | 0.0009 µA |
