164X119 Series
Manufacturer: McGill Microwave Systems
Beta
⌘K
D-SUB HIGH DENSITY CONNECTORS 26 POS HD CRIMP FEMALE THROUGH HOLE
| Part | Number of Rows | Finish | Shell Material | Ingress Protection | Mounting Type | Shell Finish Thickness | Number of Positions | Connector Style | Shell Size | Connector Layout | Contact Type | Connector Type | Flange Feature | Color | Operating Temperature (Max) | Operating Temperature (Min) | Note | Dielectric Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 McGill Microwave Systems | 3 | Tin Plated | Steel | IP20 | Free Hanging (In-Line) | 320 µin | 26 | D-Sub High Density | 2 | A DA High Density | Signal | Receptacle for Female Contacts | Housing Shell (Unthreaded) | Black | 125 °C | -55 °C | Contacts Not Included | Glass Filled Polybutylene Terephthalate (PBT) |
 McGill Microwave Systems | 3 | Tin Plated | Steel | IP20 | Free Hanging (In-Line) | 320 µin | 62 | D-Sub High Density | 4 | C DC High Density | Signal | Receptacle for Female Contacts | Housing Shell (Unthreaded) | Black | 125 °C | -55 °C | Contacts Not Included | Glass Filled Polybutylene Terephthalate (PBT) |
 McGill Microwave Systems | 3 | Tin Plated | Steel | IP20 | Free Hanging (In-Line) | 320 µin | 44 | D-Sub High Density | 3 | B DB High Density | Signal | Receptacle for Female Contacts | Housing Shell (Unthreaded) | Black | 125 °C | -55 °C | Contacts Not Included | Glass Filled Polybutylene Terephthalate (PBT) |
 McGill Microwave Systems | 4 | Tin Plated | Steel | Free Hanging (In-Line) | 78 | D-Sub High Density | 5 | D DD High Density | Signal | Receptacle for Female Contacts | Housing Shell (Unthreaded) | Black | 125 °C | -55 °C | Contacts Not Included | Glass Filled Polyester |
