84981 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
1MM FFC SMT H ASSY 6P EMBOSS
| Part | FFC, FCB Thickness | Housing Material | Voltage Rating | Mounting Type | Termination | Housing Color | Pitch [x] | Pitch [x] | Height Above Board | Height Above Board | Features | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Connector/Contact Type | Contact Finish | Number of Positions | Flat Flex Type | Cable End Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 6 | FFC FPC | Straight |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 14 | FFC FPC | Straight |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | FFC FPC | Straight | |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 18 | FFC FPC | Straight |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 21 | FFC FPC | Straight |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 20 | FFC FPC | Straight |
 TE Connectivity Raychem Cable Protection | 0.3 mm | Polyamide (PA) Nylon Glass Filled | 125 VDC | Surface Mount Right Angle | Solder | Beige | 0.039 in | 1 mm | 0.118 in | 3 mm | Solder Retention | 85 °C | -20 C | Phosphor Bronze | Contacts Top | Tin | 8 | FFC FPC | Straight |
