767017 Series

Catalog

MICT,900PLUG,114,ASSY,.025,REC

Part	Number of Positions	Height Above Board	Height Above Board	Connector Type	Pitch [x]	Pitch [x]	Contact Finish Thickness	Contact Finish Thickness	Number of Rows	Mated Stacking Heights	Mounting Type	Contact Finish
TE Connectivity Raychem Cable Protection 767017-3	114	22.66 mm	0.892 in	Outer Shroud Contacts Plug	0.64 mm	0.025 in	0.76 Ám	30 Áin	2	22.86 mm 31.9 mm	Surface Mount	Gold
TE Connectivity Raychem Cable Protection 2-767017-1	266	22.66 mm	0.892 in	Outer Shroud Contacts Plug	0.64 mm	0.025 in	0.76 Ám	30 Áin	2	22.86 mm 31.9 mm	Surface Mount	Gold
TE Connectivity Raychem Cable Protection 767017-1	38	22.66 mm	0.892 in	Outer Shroud Contacts Plug	0.64 mm	0.025 in	0.76 Ám	30 Áin	2	22.86 mm 31.9 mm	Surface Mount	Gold
TE Connectivity Raychem Cable Protection 767017-2	76	22.66 mm	0.892 in	Outer Shroud Contacts Plug	0.64 mm	0.025 in	0.76 Ám	30 Áin	2	22.86 mm 31.9 mm	Surface Mount	Gold
TE Connectivity Raychem Cable Protection 767017-4	152	22.66 mm	0.892 in	Outer Shroud Contacts Plug	0.64 mm	0.025 in	0.76 Ám	30 Áin	2	22.86 mm 31.9 mm	Surface Mount	Gold
