046207 Series

Manufacturer: Molex

Catalog

MINI-FIT JR LCP VHDR W/ PEGS 10C

Part	Style	Row Spacing - Mating	Insulation Material	Contact Type	Operating Temperature (Max)	Operating Temperature (Min)	Contact Material	Number of Positions	Termination	Contact Length - Post	Insulation Color	Number of Rows	Voltage Rating	Voltage Rating (Type)	Features	Mounting Type	Insulation Height	Contact Finish Thickness - Mating	Pitch - Mating	Fastening Type	Number of Positions Loaded	Contact Shape	Shrouding	Connector Type	Current Rating	Current Rating	Contact Finish - Post	Material Flammability Rating	Contact Finish - Mating	Applications	Contact Finish Thickness - Post
Molex 0462073010	Board Board or Cable	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin	125 °C	-40 °C	Brass Alloy	10	Solder	0.144 in	Black	2	600 V	DC	Board Guide	Through Hole	0.54 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header	0 A	Varies by Wire Gauge	Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462071206	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	6	Solder	0.207 in	Black	2				Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462070108	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	8	Solder	0.176 in	Black	2			Board Guide	Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462071006	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	6	Solder	0.144 in	Black	2				Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462073004	Board Board or Cable	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin	105 °C	-40 °C	Brass Alloy	4	Solder	0.144 in	Black	2	600 V	DC	Board Guide	Through Hole	0.54 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header	0 A	Varies by Wire Gauge	Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462070224	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	24 pos	Solder	0.207 in	Black	2			Board Guide	Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462071004	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	4	Solder	0.144 in	Black	2				Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462071104	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	4	Solder	0.176 in	Black	2				Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462074006	Board Board or Cable	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin	105 °C	-40 °C	Brass	6	Solder	0.144 in	Black	2	600 V	DC		Through Hole	0.54 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header	0 A	Varies by Wire Gauge	Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
Molex 0462070112	Board Cable/Wire	0.165 in	Glass Filled Liquid Crystal Polymer (LCP)	Male Pin			Brass	12	Solder	0.176 in	Black	2			Board Guide	Through Hole	0.535 in	100 µin	0.165 in	Locking Ramp	All	Square	Shrouded - 4 Wall	Header			Tin	UL94 V-0	Tin	General Purpose Industrial Telecommunications	100 Ąin
