IXTF02 Series
Manufacturer: LITTELFUSE
Beta
⌘K
POWER MOSFET, N CHANNEL, 4.5 KV, 200 MA, 750 OHM, ISOPLUS I4-PAK, THROUGH HOLE
| Part | Technology | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Vgs(th) (Max) | Input Capacitance (Ciss) (Max) | Current - Continuous Drain (Id) (Tc) | Vgs (Max) | Power Dissipation (Max) | Rds On (Max) | Gate Charge (Max) | Package Name | Package Leads | Drive Voltage (Max Rds On, Min Rds On) | Drain to Source Voltage (Vdss) | FET Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | MOSFET (Metal Oxide) | -55 °C | 150 °C | Through Hole | 6.5 V | 256 pF | 200 mA | 20 V | 78 W | 750 Ohm | 10.4 nC 10.4 nC | i4-Pac™-5 ISOPLUS i4-PAC™ | 3 Leads | 10 V | 4500 V | N-Channel |
 LITTELFUSE | MOSFET (Metal Oxide) | -55 °C | 150 °C | Through Hole | 4 V | 435 pF | 300 mA | 20 V | 70 W | 300 Ohm | 16.3 nC | i4-Pac™-5 ISOPLUS i4-PAC™ | 3 Leads | 10 V | 4000 V | N-Channel |
