AD9741 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
DUAL 8-BIT 250 MSPS DIGITAL-TO-ANALOG CONVERTERS
| Part | DNL (LSB) Tolerance | INL (LSB) Tolerance | Voltage - Supply, Digital (Range 2) Minimum | Voltage - Supply, Digital (Range 2) Maximum | Voltage - Supply, Digital (Range 1) Minimum | Voltage - Supply, Digital (Range 1) Maximum | Mounting Type | Architecture | Output Type | Package Length | Package Name | Package Width | Reference Type | Number of D/A Converters | Operating Temperature (Min) | Operating Temperature (Max) | Number of Bits | Package / Case | Voltage - Supply, Analog (Min) | Voltage - Supply, Analog (Max) | Differential Output | Data Interface |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 0.03 LSB | 0.05 LSB | 3.13 V | 3.47 V | 1.7 V | 1.9 V | Surface Mount | Quad-Switch | Current - Unbuffered | 10 mm | 72-LFCSP-VQ | 10 mm | External Internal | 2 count | -40 °C | 85 °C | 8 bits | 72-VFQFN Exposed Pad CSP | 3.13 V | 3.47 V | Yes | Parallel |
