AD7939 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

8-CHANNEL, 1.5 MSPS, 10-BIT PARALLEL ADCS WITH A SEQUENCER

Part	Reference Type	Sampling Rate (Per Second)	Architecture	Operating Temperature (Min)	Operating Temperature (Max)	Package / Case	Data Interface	Number of Inputs	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Ratio - ADC	Ratio - S/H	Configuration	Input Type	Mounting Type	Number of Bits	Package Length	Package Name	Package Width	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Number of A/D Converters
Analog Devices Inc./Maxim Integrated AD7939BCPZ-REEL7	External Internal	1.5 MHz	SAR	-40 °C	85 °C	32-VFQFN Exposed Pad CSP	Parallel	4 7 8	5.25 V	2.7 V	1	1	MUX-S/H-ADC	Differential Pseudo-Differential Single Ended	Surface Mount	10 bits	5 mm	32-LFCSP-VQ	5 mm	2.7 V	5.25 V	1 count
Analog Devices Inc./Maxim Integrated AD7939BCP-REEL7		1.5 MHz		-40 °C	85 °C	32-VFQFN Exposed Pad CSP	Parallel								Surface Mount	10 bits	5 mm	32-LFCSP-VQ	5 mm			1 count
Analog Devices Inc./Maxim Integrated AD7939BCP		1.5 MHz		-40 °C	85 °C	32-VFQFN Exposed Pad CSP	Parallel								Surface Mount	10 bits	5 mm	32-LFCSP-VQ	5 mm			1 count
Analog Devices Inc./Maxim Integrated AD7939BCPZ	External Internal	1.5 MHz	SAR	-40 °C	85 °C	32-VFQFN Exposed Pad CSP	Parallel	4 7 8	5.25 V	2.7 V	1	1	MUX-S/H-ADC	Differential Pseudo-Differential Single Ended	Surface Mount	10 bits	5 mm	32-LFCSP-VQ	5 mm	2.7 V	5.25 V	1 count
Analog Devices Inc./Maxim Integrated AD7939BSUZ	External Internal	1.5 MHz	SAR	-40 °C	85 °C	32-TQFP	Parallel	4 7 8	5.25 V	2.7 V	1	1	MUX-S/H-ADC	Differential Pseudo-Differential Single Ended	Surface Mount	10 bits	7 mm	32-TQFP	7 mm	2.7 V	5.25 V	1 count
Analog Devices Inc./Maxim Integrated AD7939BSUZ-REEL7	External Internal	1.5 MHz	SAR	-40 °C	85 °C	32-TQFP	Parallel	4 7 8	5.25 V	2.7 V	1	1	MUX-S/H-ADC	Differential Pseudo-Differential Single Ended	Surface Mount	10 bits	7 mm	32-TQFP	7 mm	2.7 V	5.25 V	1 count
