ADM3260 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
HOT SWAPPABLE, DUAL I2C ISOLATORS WITH INTEGRATED DC-TO-DC CONVERTER
| Part | Number of Channels | Inputs - Side 2 | Inputs - Side 1 | Type | Pulse Width Distortion (Max) (Value 1) | Pulse Width Distortion (Max) (Value 2) | Package Name | Voltage - Isolation | Common Mode Transient Immunity (Min) | Operating Temperature (Min) | Operating Temperature (Max) | Isolated Power | Mounting Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Technology | Package Width | Package Length | Channel Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | 2 | 2 | 2 | I2C | 145 ns | 85 ns | 20-SSOP | 2500 Vrms | 25 kV/µs | -40 °C | 105 °C | Yes | Surface Mount | 5.5 V | 3 V | Magnetic Coupling | 5.3 mm | 0.209 in | Bidirectional |
 Analog Devices Inc./Maxim Integrated | 2 | 2 | 2 | I2C | 145 ns | 85 ns | 20-SSOP | 2500 Vrms | 25 kV/µs | -40 °C | 105 °C | Yes | Surface Mount | 5.5 V | 3 V | Magnetic Coupling | 5.3 mm | 0.209 in | Bidirectional |
