CPC172 Series

1-FORM-A DC OPTOMOS 250V 0.09 OHMS

Catalog

1-FORM-A DC OPTOMOS 250V 0.09 OHMS

Part	Package / Case	Load Current	On-State Resistance (Max)	Circuit	Voltage - Input	Termination Style	Package Name	Approval Agency	Output Type	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Load (Max)	Mounting Type
LITTELFUSE CPC1727J	ISOPLUS264™	3.4 A	90 mOhms	SPST-NO (1 Form A)	1.2 VDC	PC Pin	ISOPLUS264™	CSA TUV UL	DC	-40 °C	85 °C	250 V	Through Hole
LITTELFUSE CPC1727J	ISOPLUS264™	3.4 A	90 mOhms	SPST-NO (1 Form A)	1.2 VDC	PC Pin	ISOPLUS264™	CSA TUV UL	DC	-40 °C	85 °C	250 V	Through Hole
LITTELFUSE CPC1728J	i4-Pac™-4 Isolated	10 A	0.1 Ohms		200 VAC	PC Pin	i4-PAC™		DC			200 V	Through Hole

Catalog

1-FORM-A DC OPTOMOS 250V 0.09 OHMS

Description

Optically isolated MOSFET-based solid state power relays in i4-PAC and ISOPLUS-264 packages feature Direct Copper Bond ceramic substrates that enable substantially lower junction-to-case thermal impedance. They are available in AC/DC and DC-only versions. For power applications requiring a heat sink for superior thermal performance, the i4-PAC and ISOPLUS-264 power relays are an ideal solution.
