TJ04 Series

Catalog

PLUGGABLE TERMINAL BLOCKS 500 TB PLU PLU W/F DOWN

Part	Pitch	Termination Style	Number of Levels	Contact Mating Finish	Wire Gauge or Range - AWG (Max)	Wire Gauge or Range - AWG (Min)	Current - UL	Wire Gauge or Range - mm² (Maximum)	Wire Gauge or Range - mm² (Minimum)	Voltage - UL	Features	Current - IEC	Color	Plug Wire Entry Angle	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - IEC	Type	Mounting Type	Positions Per Level	Number of Positions	Insulation Height	Material Flammability Rating	Screw Size	Contact Material	Torque - Screw	Housing Material	Wire Strip Length (Max)	Wire Strip Length (Min)	Wire Gauge or Range - mm²
McGill Microwave Systems TJ0471020000G	0.197 in	Screw	1	Tin	24 AWG	12 AWG	20 A	2.5 mm²	0.34 mm²	300 V	Mating Flange Retention Latches (Non-Wire Side)	20 A	Black	180 °	-40 °C	115 °C	300 V	Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0451830000G	5.08 mm	Screw	1	Tin	24 AWG	12 AWG	20 A	2.5 mm²	0.34 mm²	300 V	Retention Latches (Non-Wire Side)	20 A	Gray	180 °	-40 °C	115 °C	300 V	Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0401500000G	0.3 in	Screw	1	Tin	24 AWG	12 AWG	20 A			300 V	Retention Latches (Non-Wire Side)		Green	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0471500000G	0.197 in	Screw - Rising Cage Clamp	1	Tin	24 AWG	12 AWG	12 A	2.5 mm²	1 mm²	300 V	Retention Latches (Non-Wire Side)		Green	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper Alloy	0.56 Nm	Thermoplastic Resin	8 mm	7 mm
McGill Microwave Systems TJ0401520000G	0.3 in	Screw	1	Tin	24 AWG	12 AWG	20 A			300 V	Mating Flange Retention Latches (Non-Wire Side)		Green	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Phosphor Bronze	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0431830000G	0.15 in	Screw	1	Tin	28 AWG	16 AWG	10 A			300 V		10.5 A	Gray	180 °	-40 °C	115 °C	300 V	Female Sockets Plug	Free Hanging (In-Line)	4	4	0.437 in	UL94 V-0	M2	Phosphor Bronze		Thermoplastic	7 mm	6 mm	1.5 mm²
McGill Microwave Systems TJ0451060000G	5.08 mm	Screw	1	Tin	24 AWG	12 AWG	20 A			300 V	Retention Latches (Non-Wire Side)		Black	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0401820000G	0.3 in	Screw	1	Tin	24 AWG	12 AWG	20 A			300 V	Mating Flange Retention Latches (Non-Wire Side)		Gray	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Phosphor Bronze	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0471820000G	0.197 in	Screw	1	Tin	24 AWG	12 AWG	20 A	2.5 mm²	0.34 mm²	300 V	Mating Flange Retention Latches (Non-Wire Side)	20 A	Gray	180 °	-40 °C	115 °C	300 V	Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
McGill Microwave Systems TJ0401800000G	0.3 in	Screw	1	Tin	24 AWG	12 AWG	20 A			300 V	Retention Latches (Non-Wire Side)		Gray	180 °	-40 °C	115 °C		Female Sockets Plug	Free Hanging (In-Line)	4	4	0.594 in	UL94 V-0	M3	Copper	0.56 Nm	Thermoplastic	8 mm	7 mm
